Tractopelle Terex ELITE 860

Engine Model 1104D-44T Capacity 269in3 (4.4 ltr) Rated Speed 2200 rpm Gross Power @ 2200 rpm Cert. Rating to UN/ECE R120 74.5 (100*) kW(hp) Derived Net Rating @ 2200 rpm to ISO/80/1269/EC 65.7* (88.1*) kW(hp) Max Torque @ 1400 rpm UN/ECE R120 ISO 80/1269/EC 392 (289*) Nm(lbfft) 373* (275*) Nm(lbfft) Powershift Transmission Tyres 860 Elite Front 16/70 x 20 Rear 18.4 x 26 Travel Speeds (forward) 1st 5.9 (3.6) Km/h (mph) 2nd 9.7 (6.0) Km/h (mph) 3rd 21.9 (13.2) Km/h (mph) 4th 40.0 (24.9) Km/h (mph) Travel Speeds (reverse) 1st 5.9 (3.6) Km/h (mph) 2nd 9.7 (6.0) Km/h (mph) 3rd 21.9 (13.2) Km/h (mph) Loader Performance Standard Shovel 7-in1 Shovel Shovel Breakout 5575 (12291) kgf (lbf) 5495 (12114) kgf (lbf) Arms Breakout 4952 (10917) kgf (lbf) 5284 (11649) kgf (lbf) Lift Capacity To Full Height 3984 (8783) kg (lb) 3593 (7921) kg (lb) Backhoe Attachments Width Capacity Weight Trench Bkts 12in (305mm) 2.94ft3 (83ltrs) 207lb (94kg) 18in (450mm) 4.37ft3 (124ltrs) 247lb (112kg) 24in (600mm) 6.51ft3 (184ltrs) 295lb (134kg) 24in (600mm) 8.22ft3 (233ltrs) 295lb (143kg) 30in (750mm) 8.74ft3 (248ltrs) 342lb (155kg) 36in (900mm) 11.03ft3 (312ltrs) 390lb (177kg) Ditch cleaning 60in (1525mm) 8.0ft3 (220ltrs) 320lb (145kg) 72in (1830mm) 10.0ft3 (300ltrs) 388lb (176kg) Sq hole bucket 36in (900mm) 4.41ft3 (125ltrs) 353lb (160kg) Capacities Fuel Tank 130 (29) ltrs (gals) Engine Coolant 16.0 (3.5) ltrs (gals) Engine Oil (inc. Filter) 8.5 (1.9) ltrs (gals) Transmission 15.0 (3.3) ltrs (gals) Transmission Power shift 18.0 (4) ltrs (gals) Rear Axle 17.5 (3.9) ltrs (gals) Front Axle (4WD) 12.5 (2.7) ltrs (gals) Hydraulic System 143 (31.7) ltrs (gals) If you need more info just ask us:
